Re: Rookie help/ Advice 1968 Camaro SS

#31 Post by punisher66j » Mon Jan 27, 2014 1:01 pm

Bruce69Camaro wrote:My question is, why did this guy weld the frame mounts to the sub frame?

If this is a 366 would there be any reason to relocate the frame mounts?

If you decide to go with a small block, guess what, you'll need new frame mounts.
LOL, yeah I don't know why they did what they did but I don't know what I am doing. IF a small block goes in the car it will only be in there temporarily till I can afford a big block.

Pretty sure its a 366 after looking for what was described.


I do want to thank everyone again for all the help and info on my project.

User avatar
Bruce69Camaro
Posts: 1781
Joined: Thu Jul 23, 2009 11:07 am
Location: PA

Re: Rookie help/ Advice 1968 Camaro SS

#32 Post by Bruce69Camaro » Mon Jan 27, 2014 1:06 pm

You're not leaving already are you?

The fun just began....LOL
Those who think they know it all have no way of finding out they don't......... :scratch:

User avatar
punisher66j
Posts: 31
Joined: Mon Jan 20, 2014 10:25 am
Location: Yo Mama's House

Re: Rookie help/ Advice 1968 Camaro SS

#33 Post by punisher66j » Mon Jan 27, 2014 2:13 pm

Bruce69Camaro wrote:You're not leaving already are you?

The fun just began....LOL
LOL, NO. I am not leaving yet, just wanted to give thanks where thanks is due. I appreciate the help. Its nice to get input and views from others.

User avatar
BracketNova
Posts: 618
Joined: Sat Apr 25, 2009 6:46 pm
Contact:

Re: Rookie help/ Advice 1968 Camaro SS

#34 Post by BracketNova » Mon Jan 27, 2014 10:43 pm

I'm with John...check that bore and stroke. Plenty of racers use tall decks...you can run a longer rod that way.
"I always compare drag racing to lighting $100 bills on fire, only it's more expensive." - Craig W.

Check out my website...
http://www.findmoneyraces.com


'71 Nova E85
6.69 @ 100.2 MPH 9/6/14
1.4257 60'
1700' DA

13:1 439 BBC
3330 lbs

User avatar
punisher66j
Posts: 31
Joined: Mon Jan 20, 2014 10:25 am
Location: Yo Mama's House

Re: Rookie help/ Advice 1968 Camaro SS

#35 Post by punisher66j » Tue Jan 28, 2014 10:45 am

So just pull heads?

User avatar
John_Heard
Site Admin
Posts: 5699
Joined: Thu May 12, 2005 11:20 am
Location: Resume Speed, Kansas
Contact:

Re: Rookie help/ Advice 1968 Camaro SS

#36 Post by John_Heard » Tue Jan 28, 2014 10:52 am

Yeah you could pull one head and get cyl dia. I don't know what you have in the way of measuring tools, but you could turn it over and measure stroke as well.

User avatar
punisher66j
Posts: 31
Joined: Mon Jan 20, 2014 10:25 am
Location: Yo Mama's House

Re: Rookie help/ Advice 1968 Camaro SS

#37 Post by punisher66j » Tue Jan 28, 2014 10:55 am

John_Heard wrote:Yeah you could pull one head and get cyl dia. I don't know what you have in the way of measuring tools, but you could turn it over and measure stroke as well.
Don't really have too many measuring tools but I wouldn't know how to do that anyway.

User avatar
mytmouz
Posts: 643
Joined: Thu Sep 21, 2006 1:00 am
Location: Pelahatchie,MS

Re: Rookie help/ Advice 1968 Camaro SS

#38 Post by mytmouz » Tue Jan 28, 2014 11:20 am

A tape measure would work for this. The 427 bore is a lot bigger than the 366. A rough measurement is all you need...
Trucks are for haulin...


User avatar
Bruce69Camaro
Posts: 1781
Joined: Thu Jul 23, 2009 11:07 am
Location: PA

Re: Rookie help/ Advice 1968 Camaro SS

#39 Post by Bruce69Camaro » Tue Jan 28, 2014 11:29 am

Like mytmouz said, take of the heads and measure with a tape measure or steel rule.

A 366 has a 3.935" bore or close to 3-15/16".

A 427 has a 4.250" bore or 4-1/4".

Both of these apply unless the motor has already been bored out.
Those who think they know it all have no way of finding out they don't......... :scratch:

User avatar
punisher66j
Posts: 31
Joined: Mon Jan 20, 2014 10:25 am
Location: Yo Mama's House

Re: Rookie help/ Advice 1968 Camaro SS

#40 Post by punisher66j » Tue Jan 28, 2014 2:31 pm

How good are 500 caddy motors? I have a buddy who has one for sale for 400. its a 1976 caddy engine and auto trans.

User avatar
BracketNova
Posts: 618
Joined: Sat Apr 25, 2009 6:46 pm
Contact:

Re: Rookie help/ Advice 1968 Camaro SS

#41 Post by BracketNova » Tue Jan 28, 2014 8:48 pm

You can pick up a digital micrometer for around 30 bucks at your local(ish) parts store. This is a valuable tool to have. You can measure the bore the obvious way...to measure the stroke use the long end of the micrometer. There's a little stick that will come out the back when you open it so you would use that. Bring a piston all the way up in the hole. Use the stick to get a measurement from the surface where the head mounted to a flat spot on the piston. right that measurement down. It will be around .010 or so. Next get the piston at the bottom of the cylinder and measure to the same spot of the piston from where the head mounted. Then subtract that first measurement and that should give you an idea of the stroke. Should be around 3.76 or 4.0.
"I always compare drag racing to lighting $100 bills on fire, only it's more expensive." - Craig W.

Check out my website...
http://www.findmoneyraces.com


'71 Nova E85
6.69 @ 100.2 MPH 9/6/14
1.4257 60'
1700' DA

13:1 439 BBC
3330 lbs

User avatar
BracketNova
Posts: 618
Joined: Sat Apr 25, 2009 6:46 pm
Contact:

Re: Rookie help/ Advice 1968 Camaro SS

#42 Post by BracketNova » Tue Jan 28, 2014 8:50 pm

The caddy motor would be hard to find parts for...or at least they would be a tad more expensive due to lack of demand for them.
"I always compare drag racing to lighting $100 bills on fire, only it's more expensive." - Craig W.

Check out my website...
http://www.findmoneyraces.com


'71 Nova E85
6.69 @ 100.2 MPH 9/6/14
1.4257 60'
1700' DA

13:1 439 BBC
3330 lbs

seancarole
Posts: 15
Joined: Wed Feb 01, 2012 9:31 pm

Re: Rookie help/ Advice 1968 Camaro SS

#43 Post by seancarole » Wed Jan 29, 2014 3:40 pm

With aftermarket heads rods pistons cam intake carb or whatever you can make 800 n/a with the caddy motor.They are heavy.There are tons of good deals block chebby goodies, dare to different

User avatar
punisher66j
Posts: 31
Joined: Mon Jan 20, 2014 10:25 am
Location: Yo Mama's House

Re: Rookie help/ Advice 1968 Camaro SS

#44 Post by punisher66j » Sun Feb 02, 2014 2:43 pm

Ended up picking up a built 355 from one of my race buddys, so for now the camaro will live with a small block engine till I get a big block built.


User avatar
punisher66j
Posts: 31
Joined: Mon Jan 20, 2014 10:25 am
Location: Yo Mama's House

Re: Rookie help/ Advice 1968 Camaro SS

#45 Post by punisher66j » Sun Feb 02, 2014 2:47 pm

OH, I also "Accidently" bought this 68 caddy as well. I picked it up for 600 bucks and its in really good shape. I am just going to flip this one and make some coin for the camaro.
